Plunger: 5 micro-inch minimum Au over 50-100 micro-inch nickel Barrel: 5 micro-inch minimum Au over 50-100 micro-inch nickel
Electrical specification
Contact electrical resistor: 100 mOhm Max. Rated voltage: 12V DC Max Rated current: 1.0A
Mechanical performance
Life: 10,000 cycle min.
Applications
Intelligent Wearables
Smart watches, smart wristbands, locator devices, Bluetooth headphones, smart shoes, smart glasses, smart backpacks, etc.
Smart Home
Smart home systems, smart appliances, air purifiers, automatic controllers, and domestic automation units.
Medical & Industrial
Medical equipment, wireless charging systems, data communication hardware, telecommunications, automation, and industrial systems.
3C Consumer Electronics
Laptops, tablets, personal digital assistants (PDAs), handheld data terminals, and modern personal electronics.
Aviation & Automotive
Aviation, aerospace, military communication, military electronics, vehicles, vehicle navigation, testing fixtures, and diagnostic equipment.
Frequently Asked Questions
What materials are used in the construction of these connectors?
The plunger and barrel are made of high-conductivity Brass. The internal spring is manufactured from Stainless Steel to ensure long-term mechanical stability and durability.
What are the plating specifications for the plunger and barrel?
Both the plunger and barrel feature an electroplated surface consisting of a minimum of 5 micro-inch Au (Gold) over 50-100 micro-inch nickel. This plating provides excellent corrosion resistance and optimal electrical performance.
What are the rated electrical values for this product?
The connector is rated for a maximum voltage of 12V DC and a rated current of 1.0A. The maximum contact electrical resistance is capped at 100 mOhm.
What is the mechanical lifespan of the connector?
These connectors are engineered for high durability, with a minimum mechanical lifespan performance rating of 10,000 compression cycles.
In what industries can these connectors be applied?
They are widely applicable across diverse industries including smart home systems, smart wearables, medical devices, consumer electronics, vehicle navigation, and aerospace electronics.
